DG-800S 3.7-4.5m

Specifications:


Scale 1:4
Wing Span: 3.75-4.5 m (147-177")
Length 1.74 m (68")
Wing Area: 71.3-78.2 dm2 (1105-1212 sq. in.)
Wing Airfoil: HQ 2.5/12.5-11
Wing Loading: 65 g/dm2 (20 oz/sq. ft.)
Flying Weight: 5.0 kg (176 oz)
Radio: Standard radio
Micro servos for the wings


The DG-800S from Glasser Dirks was first introduced in 1991 and is still in production. It is available with either an 18-meter wing or a 15-meter wing with tip extensions available to make an 18-meter wing.

This kit is a nice semi-scale reproduction of this airplane at 1:4 scale. It can be flown with either 3.75 meter with or an 4.5 meter wing much like the full-scale counterpart by interchanging wingtips against winglets. The reasonable wing loading, the adequate airfoil choice makes it a great glider to tow and get into large scale soaring. The behaviour is very predictable so very easy to fly.

Content:

- White epoxy gelcoated fiberglass fuselage.
- Wings, wing tips, elevator and all moving parts are made from sheeted with obechi foam and fiberglass reinforced.
- Covered with Oracover.
- 320 mm long, double height, airbrakes installed.
- Two pairs of the winglets (wings plus the extensions).
- White gelcoated canopy frame.
- Round wing joiner, clear canopy, accessories, stickers and the step by step photo instructions.

DG-800S (3.75-4.5 m) ARF kit, price: N/A
